Khoom Description
Lub zog sib txuas tsim qauv coj vaj huam sib luag muab cov kev daws teeb meem zoo tshaj plaws rau txhua qhov kev teeb tsa uas xav tau ultra- siab txhais. Nrog lub pixel suab xws li P1.2 P1.5 P1.8 P2.0, P2.5, kev teeb tsa ntawm 2K, 4K daws teeb meem. Yog li, nws yog qhov zoo tshaj plaws thiab pheej yig rau kev siv sab hauv tsev xws li chaw tos txais neeg, digital art, pawg ntseeg, chav sib tham, khw muag khoom xav tau, khw, thiab ntau ntxiv.
Lawv muab ib qho - nres kev yuav khoom nrog peb cov ntug npog thiab phab ntsa mounting system, thiab nws nta cov kev pabcuam pem hauv ntej kom muaj kev cuam tshuam zoo - kev saib xyuas dawb, ua rau lub sijhawm tshuaj ntsuam tsawg tsawg, lawv tuaj yeem ua haujlwm thoob ntiaj teb nrog kev txhawj xeeb- dawb.
Nrog SMD thiab GOB ntim, Lawv npaj txhij los hloov txhua qhov chaw sab hauv tsev mus rau qhov pom kev zoo nkauj.
|
Qauv
|
P1.25
|
P1.86
|
P2.5
|
|
LEDType
|
SMD 1515
|
SMD 1515
|
SMD 1515
|
|
Lub cev ntom ntom (dot / m²)
|
640000
|
289050
|
160000
|
|
Module Loj (W × H × D) mm
|
320x160x17
|
320x160x17
|
320x160x17
|
|
Module daws teeb meem (W × H)
|
256x128
|
172x86
|
128x64
|
|
Txee Loj (W × H × D) mm
|
640x480x74
|
640x480x74
|
640x480x74
|
|
Txee Khoom
|
Tuag Casting Aluminium
|
Tuag Casting Aluminium
|
Tuag Casting Aluminium
|
|
Scanning hom
|
1/64
|
1/48
|
1/32
|
|
Txee Flatness (mm)
|
Tsawg dua lossis sib npaug li 0.10
|
Tsawg dua lossis sib npaug li 0.10
|
Tsawg dua lossis sib npaug li 0.10
|
|
Grey Scale (ntsis)
|
14
|
14
|
14
|
|
Qib tiv thaiv
|
IP45
|
IP45
|
IP45
|
|
Brightness (cd / ㎡)
|
500-900cd / ㎡
|
500-900cd / ㎡
|
500-900cd / ㎡
|
|
ColorTemperature
|
3200-9300Kadjustable
|
3200-9300Kadjustable
|
3200-9300Kadjustable
|
|
Brightness Uniformity
|
Ntau dua lossis sib npaug li 98%
|
Ntau dua lossis sib npaug li 98%
|
Ntau dua lossis sib npaug li 98%
|
|
Kab rov tav / Vertical ViewAngle
|
Ntau dua lossis sib npaug li 140℃/ Ntau dua lossis sib npaug li 120 degree
|
Ntau dua lossis sib npaug li 140℃/ Ntau dua lossis sib npaug li 120 degree
|
Ntau dua lossis sib npaug li 140℃/ Ntau dua lossis sib npaug li 120 degree
|
|
Qhov sib piv piv
|
Ntau dua lossis sib npaug rau 5000: 1
|
Ntau dua lossis sib npaug rau 5000: 1
|
Ntau dua lossis sib npaug rau 5000: 1
|
|
Module input voltage DC
|
5V
|
5V
|
5V
|
|
Max Refresh Rate
|
Ntau dua lossis sib npaug rau 3840Hz
|
Ntau dua lossis sib npaug rau 3840Hz
|
Ntau dua lossis sib npaug rau 3840Hz
|
|
Input voltage AC
|
110-220V
|
110-220V
|
110-220V
|
|
Txee Max Power Consumption
|
Tsawg dua lossis sib npaug li 600W / m2
|
Tsawg dua lossis sib npaug li 580W / m2
|
Tsawg dua lossis sib npaug li 480W / m2
|
|
Txawb Aver.PowerConsumption
|
Tsawg dua lossis sib npaug li 200W / m2
|
Tsawg dua lossis sib npaug li 180W / m2
|
Tsawg dua lossis sib npaug li 160W / m2
|
|
Ua haujlwm kub
|
20℃-+80 degree
|
20℃-+80 degree
|
20℃-+80 degree
|
|
Ua haujlwm av noo
|
10% -95% RH
|
10% -95% RH
|
10% -95% RH
|
|
Installation/Service Method
|
Pem hauv ntej installation / pem hauv ntej kev pab
|
Pem hauv ntej installation / pem hauv ntej kev pab
|
Pem hauv ntej installation / pem hauv ntej kev pab
|
