Technical Parameter
|
Pixel Pitch |
P0.78125 |
P0.9375 |
P1.25 |
P1.5625 |
P1.875 |
|
Lub cev ntom ntom (Dot / sqm) |
1638400 |
1137778 |
640000 |
409600 |
284444 |
|
Module loj (mm) |
150X168.75 |
300X168.75 |
300X168.75 |
300X168.75 |
300X168.75 |
|
Vaj Huam Sib Luag Dimension (WXHXD / mm) |
600X337.5X27.5 |
600X337.5X27.5 |
600X337.5X27.5 |
600X337.5X27.5 |
600X337.5X27.5 |
|
Vaj huam sib luag daws teeb meem |
768X512 |
640X360 |
480X270 |
384X216 |
320X180 |
|
Module QTY (WXH) |
4X2 |
2X2 |
2X2 |
2X2 |
2X2 |
|
Vaj huam sib luag hnyav (kg) |
4.5 |
4.5 |
4.5 |
4.5 |
4.5 |
|
Hom Kev Kho Mob |
Kev saib xyuas pem hauv ntej |
Kev saib xyuas pem hauv ntej |
Kev saib xyuas pem hauv ntej |
Kev saib xyuas pem hauv ntej |
Kev saib xyuas pem hauv ntej |
|
Txee Khoom |
Tuag-casting aluminium |
Tuag-casting aluminium |
Tuag-casting aluminium |
Tuag-casting aluminium |
Tuag-casting aluminium |
|
Brightness Carlibration |
muaj |
muaj |
muaj |
muaj |
muaj |
|
Brightness (Nts) |
Ntau dua lossis sib npaug li 600 |
Ntau dua lossis sib npaug li 600 |
Ntau dua lossis sib npaug li 600 |
Ntau dua lossis sib npaug li 600 |
Ntau dua lossis sib npaug li 600 |
|
Xim kub (K) |
1000-18500 Xaiv tau |
1000-18500 Xaiv tau |
1000-18500 Xaiv tau |
1000-18500 Xaiv tau |
1000-18500 Xaiv tau |
|
Saib lub kaum ntse ntse (V / H) |
170 degree / 170 degree |
170 degree / 170 degree |
170 degree / 170 degree |
170 degree / 170 degree |
170 degree / 170 degree |
|
Brightness / Xim uniformity |
Ntau dua lossis sib npaug li 99.8% |
Ntau dua lossis sib npaug li 99.8% |
Ntau dua lossis sib npaug li 99.8% |
Ntau dua lossis sib npaug li 99.8% |
Ntau dua lossis sib npaug li 99.8% |
|
Qhov sib piv piv |
10000 : 1 |
10000 : 1 |
10000 : 1 |
10000 : 1 |
10000 : 1 |
|
Ncej zaus |
50/60 |
50/60 |
50/60 |
50/60 |
50/60 |
|
Tsav hom |
1/48 scan |
1/46 scan |
1/45 scan |
1/48 scan |
1/45 scan |
|
Grey qib |
16bit ib |
16bit ib |
16bit ib |
16bit ib |
16bit ib |
|
Refresh tus nqi (Hz) |
3840 |
3840 |
3840 |
3840 |
3840 |
|
Max. Kev siv hluav taws xob (W / sqm) |
420 |
420 |
420 |
420 |
420 |
|
Avg. Kev siv hluav taws xob (W / sqm) |
100 |
100 |
100 |
100 |
100 |
|
Kev tiv thaiv qib |
IP31 |
IP31 |
IP31 |
IP31 |
IP31 |
|
Lub zog nkag |
AC 90-264V, 47-63Hz |
||||
|
Ua haujlwm kub / av noo (degree / RH) |
-20 ~ 60 degree / 10% ~ 85% |
||||
|
Cia kub / av noo (degree / RH) |
-20 ~ 60 degree / 10% ~ 85% |
||||
Nta
1.Wide colour gamut + HDR High colour coverage, precisely reproduction of natural colours, ua daim duab ntau tiag tiag HDR muaj peev xwm rov tsim dua lub siab ncov ntawm High dynamic ntau yam duab thiab tso saib cov ntsiab lus ntxiv
2.Cabinets seamless splicing ua 2K, 4K, 8 thiab 16 K ultra siab txhais LED npo
3.High refresh rate High grey nplai
4.170 degree Super wide viewing angle Zoo meej kev nthuav qhia ntawm cov duab los ntawm txhua lub kaum ntse ntse
5. Kev saib xyuas pem hauv ntej tuaj yeem siv rau qhov chaw sib txawv installation
6.Seamless Splicing Tuag-casting Alumium Txee nrog CNC high-precision ua
(Cabinet of Cabinet Tsawg dua los yog sib npaug rau 0.1mm) Screwless tsim kom sai thiab ruaj ntseg installation Super ntsiag to fanless tsim
(Cabinet of Cabinet Tsawg dua los yog sib npaug rau 0.1mm) Screwless tsim kom sai thiab ruaj ntseg installation Super ntsiag to fanless tsim
Jiulong Optoelectronics tau kho nws cov khoom tsim khoom raws li cov neeg siv khoom xav tau nyob rau xyoo tas los no. Txawm hais tias nws yog me me pitch LED screen lossis qiv coj screen, peb muaj kev lag luam zoo. Nyob rau hauv lub neej yav tom ntej, peb tseem yuav ua hauj lwm nyuaj, txuas ntxiv mus hla kev nyuaj, thiab txuas ntxiv txhim kho qhov yooj yim, ceev, thiab cov khoom siv LED zoo rau peb cov neeg siv khoom.
