Technical Parameter
|
Qauv NO. |
P1.953 |
P2.604 |
P2.976 |
P3.91 |
P4.81 |
|
Pixel Pitch |
1.95mm ib |
2.6mm ib |
2.9mm ib |
3, 91mm |
4.81mm ib |
|
LED hom |
SMD 1415 |
SMD 415 |
SMD1921 |
SMD1921 |
SMD 2525 |
|
Flatness ntawm modules |
Tsawg dua los yog sib npaug rau 0.1mm |
Tsawg dua los yog sib npaug rau 0.1mm |
Tsawg dua los yog sib npaug rau 0.1mm |
Tsawg dua los yog sib npaug rau 0.1mm |
Tsawg dua los yog sib npaug rau 0.1mm |
|
Pixel configuration |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
|
Module loj (W * H) |
250 * 250 hli |
250 * 250 hli |
250 * 250 hli |
250 * 250 hli |
250 * 250 hli |
|
Module daws teeb meem (W * H) |
128 * 128 hli |
96 * 96 hli |
84 * 84mm |
64 * 64mm |
52 * 52 hli |
|
Txee loj (W * H * D) |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
|
Txee daws teeb meem (W * H) |
256 * 512 hli |
192 * 384 hli |
168 * 336 hli |
128 * 256 hli |
104 * 208 hli |
|
Txee hnyav |
14.5kg / pcs |
14.5kg / pcs |
14.5kg / pcs |
14.5kg / pcs |
14.5kg / pcs |
|
Qhov ntom |
262144 dots/m² |
147456 dots/m² |
PEB 112896 dots/m² |
65400 dots/m² |
43264 dots/m² |
|
IC |
2153 |
2153 |
2153 |
2153 |
2153 |
|
Luam theej duab |
32S |
32S |
21S |
16S |
13S |
|
Qhov zoo tshaj plaws saib nyob deb |
>1.9m |
>2.6m |
>3m |
>4m |
>5m |
|
Qhov pom qhov zoo tshaj plaws |
160 degree / 120 degree |
160 degree / 120 degree |
160 degree / 120 degree |
160 degree / 120 degree |
160 degree / 120 degree |
|
Brightness |
5500-6000cd/m² |
5500-6000cd/m² |
6000-6500cd/m² |
6000-6500cd/m² |
6500-7000cd/m² |
|
Ua haujlwm voltage |
AC: 110-240V 50 ~ 60Hz |
AC: 110-240V 50 ~ 60Hz |
AC: 110-240 V 50 ~ 60Hz |
AC: 110-240V 50 ~ 60Hz |
AC: 110-240V 50 ~ 60Hz |
|
Lub zog siab tshaj plaws |
Tsawg dua lossis sib npaug li 600W / m² |
Tsawg dua lossis sib npaug li 600W / m² |
Tsawg dua lossis sib npaug li 600W / m² |
Tsawg dua lossis sib npaug li 600W / m² |
Tsawg dua lossis sib npaug li 600W / m² |
|
Kev siv hluav taws xob nruab nrab |
100W/m² |
200W/m² |
200W/m² |
200W/m² |
200W/m² |
|
~300W / m² |
~300W / m² |
~300W / m² |
~300W / m² |
~300W / m² |
|
|
Screen kub nce (khiav lub xeev) |
Tsawg dua lossis sib npaug li 5 degrees |
Tsawg dua lossis sib npaug li 5 degrees |
Tsawg dua lossis sib npaug li 5 degrees |
Tsawg dua lossis sib npaug li 5 degrees |
Tsawg dua lossis sib npaug li 5 degrees |
|
Kev ua haujlwm ntawm Environmental Temperature / degree |
-10 degree ~ 60 degree |
-10 degree ~ 60 degree |
-10 degree ~ 60 degree |
-10 degree ~ 60 degree |
-10 degree ~ 60 degree |
|
Ua haujlwm kub |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
|
Tsis muaj condensation |
Tsis muaj condensation |
Tsis muaj condensation |
Tsis muaj condensation |
Tsis muaj condensation |
|
|
Screen xim kub |
2000K~9500K |
2000K~9500K |
2000K~9500K |
6500K~9500K |
7000K~10000K |
|
Txoj kev tsav tsheb |
1/32 scanning |
1/32 scanning |
1/32 scanning |
1/16 scanning |
1/16 scanning |
|
Grey nplai |
16 bits |
16 bits |
16 bits |
16 bits |
16 bits |
|
Hloov tshiab zaus |
Ntau dua lossis sib npaug rau 3840Hz |
Ntau dua lossis sib npaug rau 3840Hz |
Ntau dua lossis sib npaug rau 3840Hz |
Ntau dua lossis sib npaug rau 3840Hz |
Ntau dua lossis sib npaug rau 3840Hz |
|
IP qib |
Pem hauv ntej: IP68 |
Pem hauv ntej: IP68 |
Pem hauv ntej: IP68 |
Pem hauv ntej: IP68 |
Pem hauv ntej: IP68 |
|
Tom ntej: IP66 |
Tom ntej: IP66 |
Tom ntej: IP66 |
Tom ntej: IP66 |
Tom ntej: IP66 |
|
|
Lub sijhawm ua haujlwm tsis tu ncua |
Ntau dua lossis sib npaug li 7 × 24 teev |
Ntau dua lossis sib npaug li 7 × 24 teev |
Ntau dua lossis sib npaug li 7 × 24 teev |
Ntau dua lossis sib npaug li 7 × 24 teev |
Ntau dua lossis sib npaug li 7 × 24 teev |
|
Lub neej |
100, 000 teev |
100, 000 teev |
100, 000 teev |
100, 000 teev |
100, 000 teev |
|
Txoj kev teeb tsa |
Back Frame Installation / Hoisting / Inner Arc Installation |
||||
|
Pixel kho |
Nruab nrog point - los ntawm - point brightness thiab chromaticity kho |
||||
|
Tswj hom |
Synchronization tswj |
||||
|
Tswj nrug |
Super tsib ob stranded network cable, ntau tshaj 100 meters siv optical fiber kis tau tus mob |
||||
|
Software interface |
Windows XP / 7/8/10 IOS |
||||
|
Teeb liab input |
HDMI, DVI, VGA, USB, LAN (Extensible interface) |
||||
|
Cov khoom siv txee |
Waterproof Tuag-casting Aluminium |
||||
|
Lub zog Con |
Neut rick Fais fab txuas nrog cable |
||||
|
Ether Con |
Neut rick Fais fab txuas nrog cable |
||||
|
Txoj kev tu |
Dual Service, Pem Hauv Ntej Kho thiab Back Service |
||||
|
Lub sijhawm lav |
3 xyoo warranty lub sijhawm thiab kev pabcuam pub dawb rau lub neej |
||||
Nta
1.suitable rau sab hauv tsev thiab sab nraum zoov theem / concerts
2. Lub teeb thiab nyias: ib lub thawv hnyav 5-7.5 kg thiab yog 70-100 hli tuab;
3. Kev hloov tshiab siab heev: Nws tuaj yeem lav tias, thaum tua, lub koob yees duab siab thiab lub koob yees duab tuaj yeem ntes cov duab ilv thiab siab txhais;
4. Tsis tshua muaj kev ci ntsa iab thiab kev ua haujlwm siab grey: Ntawm qhov ci ntsa iab, muaj cov duab zoo sib xws thiab sib xws hauv cov nplai grey;
5. High contrast grille screen: cov nyhuv zoo, pom lub kaum ntse ntse, tsis muaj qhov cuam tshuam, tsim daim npog ntsej muag, thiab lub cev dub SMD;
6. zoo heev uniformity ntawm cov xim thiab brightness: kom lav zoo uniformity, hwm lub teeb-emitting li xaiv los ntawm tib batch yog siv;
7. Lub vijtsam grille muaj kev vam meej thiab siv tau ntev heev vim tias nws siv cov khoom siv hluav taws xob txuas ncaj qha rau ntawm lub rooj tsavxwm tsim, uas ua rau kev sib txuas sab hauv yooj yim dua, txo qhov teeb meem ntawm kev sib txuas tsis zoo, thiab txo qis kev cuam tshuam thiab teeb liab attenuation. Ntev lifespan thiab zoo heev dependability yog guaranteed los ntawm superior lub teeb-emitting li;
8. Ceev thiab yooj yim splicing, kho tau yooj yim, thiab kev txij nkawm tsawg: kev siv xauv xauv yooj yim, cuab yeej-dawb splicing;
9. Tsis muaj suab nrov: tsim kev ntsiag to, tsis muaj kev teeb tsa rau cov kiv cua lossis cua txias, tsis muaj suab nrov, tsis siv hluav taws xob tsawg, thiab txuag hluav taws xob thiab hluav taws xob;
10. Lub vijtsam grille lub sijhawm kuaj pom qhov yuam kev tiag tiag: Tsis tas yuav tsum muaj cov khoom siv sab nraud ntxiv, nws tuaj yeem txiav txim siab tus kheej seb txhua lub LED qhib Circuit Court, tshem tawm cov teeb meem zoo li cov ntoo khaub lig uas tshwm sim los ntawm qhov no.
