Technical Parameter
|
Qauv NO. |
P1.953 |
P2.604 |
P2.976 |
P3.91 |
P4.81 |
|
Pixel Pitch |
1.95mm ib |
2.6mm ib |
2.9mm ib |
3, 91mm |
4.81mm ib |
|
LED hom |
SMD 1415 |
SMD 415 |
SMD1921 |
SMD1921 |
SMD 2525 |
|
Flatness ntawm modules |
Tsawg dua los yog sib npaug rau 0.1mm |
Tsawg dua los yog sib npaug rau 0.1mm |
Tsawg dua los yog sib npaug rau 0.1mm |
Tsawg dua los yog sib npaug rau 0.1mm |
Tsawg dua los yog sib npaug rau 0.1mm |
|
Pixel configuration |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
|
Module loj (W * H) |
250 * 250 hli |
250 * 250 hli |
250 * 250 hli |
250 * 250 hli |
250 * 250 hli |
|
Module daws teeb meem (W * H) |
128 * 128 hli |
96 * 96 hli |
84 * 84mm |
64 * 64mm |
52 * 52 hli |
|
Txee loj (W * H * D) |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
|
Txee daws teeb meem (W * H) |
256 * 512 hli |
192 * 384 hli |
168 * 336 hli |
128 * 256 hli |
104 * 208 hli |
|
Txee hnyav |
14.5kg / pc |
14.5kg / pc |
14.5kg / pc |
14.5kg / pc |
14.5kg / pc |
|
Qhov ntom |
262144 dots/m² |
147456 dots/m² |
PEB 112896 dots/m² |
65400 dots/m² |
43264 dots/m² |
|
IC |
2153 |
2153 |
2153 |
2153 |
2153 |
|
Luam theej duab |
32S |
32S |
21S |
16S |
13S |
|
Qhov zoo tshaj plaws saib nyob deb |
>1.9m |
>2.6m |
>3m |
>4m |
>5m |
|
Qhov pom qhov zoo tshaj plaws |
160 degree / 120 degree |
160 degree / 120 degree |
160 degree / 120 degree |
160 degree / 120 degree |
160 degree / 120 degree |
|
Brightness |
5500-6000cd/m² |
5500-6000cd/m² |
6000-6500cd/m² |
6000-6500cd/m² |
6500-7000cd/m² |
|
Ua haujlwm voltage |
AC: 110-240V 50 ~ 60Hz |
AC: 110-240V 50 ~ 60Hz |
AC: 110-240 V 50 ~ 60Hz |
AC: 110-240V 50 ~ 60Hz |
AC: 110-240V 50 ~ 60Hz |
|
Lub zog siab tshaj plaws |
Tsawg dua lossis sib npaug li 600W / m² |
Tsawg dua lossis sib npaug li 600W / m² |
Tsawg dua lossis sib npaug li 600W / m² |
Tsawg dua lossis sib npaug li 600W / m² |
Tsawg dua lossis sib npaug li 600W / m² |
|
Kev siv hluav taws xob nruab nrab |
100W/m² |
200W/m² |
200W/m² |
200W/m² |
200W/m² |
|
~300W / m² |
~300W / m² |
~300W / m² |
~300W / m² |
~300W / m² |
|
|
Screen kub nce (khiav lub xeev) |
Tsawg dua lossis sib npaug li 5 degrees |
Tsawg dua lossis sib npaug li 5 degrees |
Tsawg dua lossis sib npaug li 5 degrees |
Tsawg dua lossis sib npaug li 5 degrees |
Tsawg dua lossis sib npaug li 5 degrees |
|
Kev ua haujlwm ntawm Environmental Temperature / degree |
-10 degree ~ 60 degree |
-10 degree ~ 60 degree |
-10 degree ~ 60 degree |
-10 degree ~ 60 degree |
-10 degree ~ 60 degree |
|
Ua haujlwm kub |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
|
Tsis muaj condensation |
Tsis muaj condensation |
Tsis muaj condensation |
Tsis muaj condensation |
Tsis muaj condensation |
|
|
Screen xim kub |
2000K~9500K |
2000K~9500K |
2000K~9500K |
6500K~9500K |
7000K~10000K |
|
Txoj kev tsav tsheb |
1/32 scanning |
1/32 scanning |
1/32 scanning |
1/16 scanning |
1/16 scanning |
|
Grey nplai |
16 bits |
16 bits |
16 bits |
16 bits |
16 bits |
|
Hloov tshiab zaus |
Ntau dua lossis sib npaug rau 3840Hz |
Ntau dua lossis sib npaug rau 3840Hz |
Ntau dua lossis sib npaug rau 3840Hz |
Ntau dua lossis sib npaug rau 3840Hz |
Ntau dua lossis sib npaug rau 3840Hz |
|
IP qib |
Pem hauv ntej: IP68 |
Pem hauv ntej: IP68 |
Pem hauv ntej: IP68 |
Pem hauv ntej: IP68 |
Pem hauv ntej: IP68 |
|
Tom ntej: IP66 |
Tom ntej: IP66 |
Tom ntej: IP66 |
Tom ntej: IP66 |
Tom ntej: IP66 |
|
|
Lub sijhawm ua haujlwm tsis tu ncua |
Ntau dua lossis sib npaug li 7 × 24 teev |
Ntau dua lossis sib npaug li 7 × 24 teev |
Ntau dua lossis sib npaug li 7 × 24 teev |
Ntau dua lossis sib npaug li 7 × 24 teev |
Ntau dua lossis sib npaug li 7 × 24 teev |
|
Lub neej |
100, 000 teev |
100, 000 teev |
100, 000 teev |
100, 000 teev |
100, 000 teev |
|
Txoj kev teeb tsa |
Back Frame Installation / Hoisting / Inner Arc Installation |
||||
|
Pixel kho |
Nruab nrog point - los ntawm - point brightness thiab chromaticity kho |
||||
|
Tswj hom |
Synchronization tswj |
||||
|
Tswj nrug |
Super tsib ob stranded network cable, ntau tshaj 100 meters siv optical fiber kis tau tus mob |
||||
|
Software interface |
Windows XP / 7/8/10 IOS |
||||
|
Teeb liab input |
HDMI, DVI, VGA, USB, LAN (Extensible interface) |
||||
|
Cov khoom siv txee |
Waterproof Tuag-casting Aluminium |
||||
|
Lub zog Con |
Neut rick Fais fab txuas nrog cable |
||||
|
Ether Con |
Neut rick Fais fab txuas nrog cable |
||||
|
Txoj kev tu |
Dual Service, Pem Hauv Ntej Kho thiab Back Service |
||||
|
Lub sijhawm lav |
3 xyoo warranty lub sijhawm thiab kev pabcuam pub dawb rau lub neej |
||||
Nta
1.Thin thiab lub teeb lub thawv tsim txuag nqi shipping
2.Txoj kev sib txuas tsim, yooj yim rau nruab thiab tshem tawm
3. Ob qho tib si pem hauv ntej thiab nraub qaum yog ua tau, 500mm txog 500x1000mm txee qhov ntau thiab tsawg.
4.Indoor zaub screen tsim, siab brightness, siab refresh npaum li cas, ntshiab xim
5.Nova system txhawb, kev ua haujlwm yooj yim thiab yooj yim
6.Cov khoom txhawb customization thiab cov ntawv tuaj yeem kho
7. Flight case ntim rau kev thauj mus los yooj yim thiab tuav
