1. Lub npov P1.5 yog tsim los ua 16: 9 rau kev hais kom ua thiab kev tswj hwm thiab kev ruaj ntseg saib xyuas cov ntxaij vab tshaus, yooj yim hloov 4: 3 lossis 16: 9 cov khoom siv ib txwm siv;
2. Tuag-cam khwb cia txhuas lub thawv nrog siab precision kom lub vijtsam du thiab seamless;
3. Muaj kev hloov kho screws nyob rau sab saum toj, hauv qab, sab laug thiab sab xis hauv lub thawv P1.5 LED zaub, uas tuaj yeem kho qhov teeb meem ntawm cov kab ci thiab tsaus nti raws li qhov xwm txheej; muaj tiag tiag tsis muaj ci thiab tsaus kab;
4. Sib nqus module tsim, lub module, daim npav system thiab lub hwj chim muab tag nrho cov kev txhawb nqa pem hauv ntej, thiab tag nrho cov ntawv teev lus thiab cov khoom siv fais fab yog muab ob npaug rau;
5. Lub P1.5 puv xim LED zaub npo muaj cov duab zoo ib yam thiab siv cov tshuab tsis-linear point-by-point kho tshuab ua kom cov duab pom tseeb thiab muaj kev nkag siab zoo ntawm txheej txheej;
6. P1.5 puv xim zaub muaj 140-degree saib lub kaum sab xis nce, nqis, sab laug, thiab sab xis, tshaj tawm-theem xim gamut, thiab ntse hloov xim kub thiab ci ntsa iab, ua rau nws haum rau ntev- lub sij hawm saib;
7. Kev lag luam-ua 6H thev naus laus zis, ua tiav qhov ci ntsa iab, siab grey, siab anti-static, thiab siab refresh;
Parameter
|
|
Mod NO. |
JL-PH1.538-52scan |
|
Module loj |
320mm * 160mm |
|
|
Lub cev ntom ntom |
422500 dot/m2 |
|
|
Ntim hom |
SMD 3IN 1-1212 |
|
|
Module Kev daws teeb meem |
208 dots (W) x 104 teev (H) |
|
|
Scan hom |
1/52 scan |
|
|
Module thickness |
18 hli |
|
|
Txee Loj |
640 x 480 mm |
|
Rooj daws teeb meem |
416 (W) x 312 hli (H) |
|
|
Rate refresh |
3840 Hz |
|
|
Brightness |
700cd / ㎡ |
|
|
Input voltage |
110-220V; AC ± 10% |
|
|
zoo tshaj plaws saib lub kaum sab xis |
H: 140 degree; V: 120 degree |
|
|
Ua haujlwm kub |
-20 degree ~ +50 degree |
|
|
PIB: P1.538 |
|
Loj: 3.84x2.24M |
|
|
Daws teeb meem: 2496x1456px |
|
|
Chaw nyob: United States |
|
|
Tswj system: Nova-star |
|
|
Video processor: VX600 |
|
|
Module loj: 320x160MM |
Txoj kev teeb tsa
1. Phab ntsa mounted installation
2. Pem teb mounted installation
3.Txoj kev teeb tsa
4.Cantilever installation
FAQ
Jiulong Optoelectronics tsom rau kev tshawb fawb thiab kev tshawb fawb ntawm LED loj-screen zaub daim ntawv thov. Peb tsis tsuas yog tsim LED zaub loj cov ntxaij vab tshaus, tab sis kuj muab koj nrog kev tshaj lij-theem zaub daws teeb meem tsim thiab cov kev pabcuam zoo tshaj plaws rau kev siv thev naus laus zis.
Peb maily tsim ruaj sab hauv tsev thiab sab nraum zoov coj zaub, xauj coj zaub, HD me me pitch coj zaub, coj daim ntawv tshaj tawm, cob coj zaub thiab lwm yam.
